Small plate vibratory compactor for sale

Payment Type: T/T,Paypal,Money Gram,Western Union
Incoterm: FOB,CFR,CIF,EXW,FCA,CPT,CIP
Min. Order: 1 Set/Sets
Delivery Time: 5 Days

Basic Info

Model No.: STP160

Type: Rammer Compactor

Working Method: Vibration

Compaction Depth: 25cm

Engine Type: Petrol Engine

Travel Speed: 35cm/s

Centrifugal Force: 13.5KN

Certification: SGS, CE

Condition: New

Engine: HONDA GX160/GX270

Power: 5.5HP

Weight: 160Kgs

Plate Size: 73*37cm

Working Size: 125*37*93cm

Additional Info

Packaging: Packed into wooden box or Canton box

Productivity: 1000 sets per month

Brand: Storike

Transportation: Ocean,Land,Air

Place of Origin: Shandong,jining

Supply Ability: 1000 sets per month

Certificate: CE & ISO certification

HS Code:  8430610000

Port: Qingdao Port

Product Description

Small plate vibratory compactor for sale


Hydraulic reversible plate compactor
The hydraulic system adjusts travel control lever for smooth changing of direction. Speed is adjusted through hydraulic control of the eccentric element. This gives the plate compactor smooth motion and makes it easy to operate. It is used for compaction work close to piles and concrete bases. Excellent for floor fillings foundations, road repairs as well as backfill in pipe trenches.

Shandong Storike Engineering Machinery Co.,Ltd. is specialized in the sales and production of Road roller Plate Compactor,Tamping Rammer,Tower,Concrete Truss screed machine,Power Trowel,Crack Sealing Machine,Concrete Scarifier ,Cutter,Slotting Machine and Hydraulic Power Unit And Tools other construction machine. Our products are widely used in municipal and highway pavement road roller maintenance, small area compacting and depressed trough and so on. Our equipment is favored by many construction companies and have a large market in China. More and more trading companies purchase equipment from our plants, so we decide to enter world market with more favorable price to shape our product brand and provide the best after-sale service. If you are interested in our machine, contact us!
Feature



Long life
Less maintenance with high wear resistant and self-cleaning cast iron base plate.



Safety and reliability

The large size engine frame gives outstanding protection against damage.
External cage to protect the plate from accidental damage.
The V-belt drive is fully enclosed for better safety and trouble free use.

More efficiency
Infinitely variable centrifugal force, infinitely variable forward and reverse speed and stationary vibration for maximum flexibility on a wide range of soil conditions.

More utilisation
Properly curved edges for easy access to corners during compaction.


Machine Parts



Handle:

Foldable handle easy for transportation.

The designing of square-shaped bed and handle is more helpful and comfortable for the operators to changing working directions.

Option item:


*Other engine are available as requested

*Water tank can be assembled as requested

*Optional rubber mat for brick paving compaction

Plate compactor 1




Product Description




Model

STP-60

STP-90

STP-125

STP-160

Engine

HONDA GX160

HONDA GX160

HONDA GX160

HONDA GX160

Engine type

Gasoline Air cooling

Gasoline Air cooling

Gasoline Air cooling

Gasoline Air cooling

Power(HP)

5.5

5.5

5.5

5.5

Work Speed(m/min)

34

23

28

27

Exciting Force(KN)

10.5

15

25

30.5

Excitation Frequency(HZ)

93

92

72

67

Work Efficiency(sq.m./hr)

423

405

400

500

Compaction Depth(cm)

20

30

30

50

Working weight(KG)

66

90

125

159

Plate size(cm)

50*35

53*50

62*40

73*37

Rammer size(mm)

L1080*W350 *H850

L1100*W500 *H850

L1200*W400 *H930

L1250*W370 *H930

Our Products

 2

Product details

 3

Product Application
4

Our products are used for compaction of soil, asphalt roads, sidewalks, Bridges, car parks, sports venues and narrow field compaction, it is an ideal equipment of small compaction construction project.



Payment

 5

Packaging & Shipping

 6

Plate Compactor
